Helical Knife Nc Cut Off 1.4m Corrugated Cardboard Making Machine

Name: Helical Knife Nc Cut Off 14m Corrugated Cardboard Making Machine
Brand: AODONG
Price: 7000 USD

Helical Knife Nc Cut Off 1.4m Corrugated Cardboard Making Machine Manufactures

Brand Name : AODONG

Model Number : AO-2010

Certification : ISO9001

Place of Origin : CN

MOQ : 1 set

Price : 7000 USD

Payment Terms : L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 15 sets per years

Delivery Time : 35 days

Packaging Details : woods

Voltage : 220v/380v/440v

Condition : New

Type : Packaging Line

After-sales service provided : Engineers available to service machinery overseas

Weight : 60T

Driven type : Electric

Application : Machinery & Hardware

Packaging material : Metal

Packaging type : Cartons

Warranty : 2 years

Power : as requested

Name : 5 ply fully automatic box corrugated cardboard making machine price

Usage : Hydraulic Mill Roll Stand of Corrugated Cardboard Packing Machine

Function : High Efficiency

Machine type : Carton Packaging Machinery

Contact Now

Helical Knife NC Cut Off Machine Of Corrugated Card Board Production Line

Uses and characteristics:

◆ Design speed: 200m/min；;

◆ Effective width: 1400mm-2500mm；;

◆ paper cutting length 500mm-9999mm, paper cutting accuracy ±1mm (at uniform speed).

◆ Automatic circulating lubrication with oil pump.

◆ Precision adjustable gapless gear ensures accurate meshing of knife edges and balanced operation.

◆ The computer automatically adjusts the paper cutting speed according to the specifications and production speed of paperboard, keeping synchronization.

◆ The computer can store multiple sets of orders, the man-machine interface is separated, and the screen displays various production information, which can

Check, modify, add and cancel at any time.

◆ "Scissors" progressive spiral cutting is adopted, which has small impact and high paper cutting precision.

◆ Double sun gear paper pressing structure is adopted to ensure the cutting accuracy of paperboard.
